NEW 2025 LS MT225S-HT Tractor – Stock#0003001
618-658-1902
Advertised Price $21,920.00
Financing Options

The 2025 LS MT225S-HT Tractor is a premium compact tractor designed for versatility and efficiency. It features a 24.7-horsepower Yanmar 3-cylinder diesel engine, delivering reliable performance for various tasks. The tractor is equipped with a 3-range hydrostatic transmission, allowing smooth operation and precise control. Its high-capacity loader offers a lift capacity of 1,067 lbs, while the three-point hitch can lift up to 1,896 lbs, making it suitable for a wide range of implements. Additional features include excellent visibility, an ergonomically designed integrated loader joystick, and advanced lighting for enhanced operator comfort and productivity.

MakeLS Tractor
ModelMT225S-HT
Year2025
MilesNew
Engine24.7HP Yanmar 3 Cylinder-IDI

Tab

Specifications

Specifications

Engine

Type 3 Cylinder-IDI
Model (Tier 4)  3TNV80F-ZXKLST(YANMAR)
Engine HP (Gross 24.7
PTO HP 19.3
Rated Speed (RPM) 2,800
Displacement (cu. in) 77.3
Fuel Tank Capacity (gal) 6.79
Alternator (V-A) 12V-40

Drive Train

Transmission Type HST
No. of Speed 3 Ranges
Brakes Wet, Multi-disc
Steering Hydrostatic Power Steering

PTO

Type Independent
Rear, rpm 540 (Standard)
Mid PTO 2,500 (Option)

Hydraulic System

Control System Position
Implement pump (gpm) 5.6
Steering pump (gpm) 3.7
Total flow (gpm) 9.3
Category, 3 pt hitch CAT I
Hitch Lift capacity, lbs (Hitch end) 1,896
Remote Valves 1 Pair (Option)

Dimension

Overall length (Frame to Link, in.) 111.9
Overall width with tires (in.) 48.7
Wheelbase (in.) 63.4
Height to top (in.) 86.4

Tire Size



IND Front / Rear 23 x 8.5 – 12 / 12 – 16.5
Versa Turf Front / Rear 12 x 16.5/23 x 8.5

Weight

Total weight without ballast (lbs.) 1,764

Tab

Key Features

  • Excellent Visibility
  • Ergonomically Designed Integrated Loader Joystick
  • Ergonomic Design Featuring Electric PTO
  • Transmission and PTO Engagement Levers
  • Standard Cupholder
  • 2 Pedal 3 Rand Hydrostatic Transmission
  • Deck Height Adjustment
  • Advanced Lighting

Options

LL2300

  • Maximum Lift height (in): 84.4
  • Clearance with Attachment Dump (in): 59.1
  • Reach at Maximum Height (in): 17.8
  • Maximum Dump Angle (deg.) 55
  • Maximum Rollback Angle (deg.): 40
  • Digging Depth (in): 4.5
  • Overall Height in Carry Position (in): 45.9
  • Lift Capacity(@ Pivot pin) (lbs.): 1,067
