NEW 2025 LS MT232-HT-C Tractor – Stock#0003003
618-658-1902
Advertised Price $36,160.00
Financing Options

The 2025 LS MT232-HT-C Tractor is a robust compact tractor designed for a variety of agricultural and landscaping tasks. It is powered by a 31.7-horsepower engine, providing ample power for demanding applications. The tractor features a 3-range hydrostatic transmission with linked pedal functionality, allowing for smooth and efficient operation. Its redesigned air conditioning and roof configuration offer increased head space and improved forward visibility, enhancing operator comfort. Additional features include a new hood design with a 20% larger grill opening, LED headlights, and a choice of four different tire options, including 1-inch larger tires for improved traction.

MakeLS Tractor
ModelMT232-HT-C
Year2025
MilesNew
EngineYanmar 3 Cylinder Liquid-cooled Diesel, NA, CRDI

Tab

Specifications

Specifications

Engine

Type 3 Cylinder Liquid-cooled Diesel, NA, CRDI
Model (Tier 4) YANMAR
Engine HP (Gross) 31.7
PTO HP 26.2
Rated Speed (RPM) 2,600
Displacement (cu. in) 100.2
Fuel Tank Capacity (gal) 11.4
Alternator (V-A) 12V – 55 Amps

Drive Train

Transmission Type HST
No. of Speed 3 Ranges
Brakes Wet, Multi-disc
Steering Hydrostatic Power Steering

PTO

Type Independent
Rear, rpm 540 (Standard)

Hydraulic System

Control System Position
Implement pump (gpm) 6.7
Steering pump (gpm) 5.0
Total flow (gpm) 11.7
Category, 3 pt hitch CAT I
Hitch Lift capacity, lbs (Hitch end) 1,808
Remote Valves 1 Pair

Dimension

Overall length (Frame to Link, in.) 125
Overall width with tires (in.) 66
Wheelbase (in.) 69
Height to top (in.) 90

Tire Size

Ag Front / Rear 7 – 14 / 11.2 – 24
IND Front / Rear 27X8.50-15 / 43X16.00-20
VT Front / Rear 27X8.50-15 / 43X16.00-20
Turf Front / Rear 25X8.50-14 / 41X14.00-20

Weight

Total weight without ballast (lbs.) 3,721

Tab

Key Features

  • Redesigned air conditioning and roof configuration, providing additional head space and increased forward visibility
  • Much improved seat comfortability
  • Cruise control & linked pedal functionalities (Engine RPM matches user input demand on F/R HST pedals)
  • New hood design (LS Family look), Grill open space plus 20%
  • LED head Lamp
  • 1 Inch large tire size and four different tire options
  • Larger lifting capacity, loader lifting capacity of New MT226E (LL3301/2) 1,965 lbs. New MT2E & MT2 (LL3303) 2,506lbs.
  • Workability, 4-point mount structure as well as digging depth of 97.2” and bucket digging force of 3,663lbs.
  • TF-LCD instrument panel providing various information like, regen time, oil change interval, etc.
  • E/G RPM interlocking switch (STD). When working at low RPM, instantaneous RPM can be increased by simply manipulating the toggle switch to momentarily increase loader speed/lift.

Options

LL3003

  • Bucket (in.): 66
  • Maximum Lift height (in.): 94.3
  • Clearance with Attachment Dump (in.): 67
  • Reach at Maximum Height (in.): 14.4
  • Maximum Dump Angle (deg.): 48
  • Maximum Rollback Angle (deg.): 42.5
  • Digging Depth (in.): 4.8
  • Overall Height in Carry Position (in.): 51.2
  • Lift Capacity (Bucket Pivot Pin, MAX, Height) (lbs): 2,063
  • Lift Capacity (Pivot pin @ 1.5m) (lbs.): 2,506
  • Breakout Force(@ Pivot pin) (lbs.): 3,723
  • Approx. Weight (Loader w/o Bucket) (lbs.): 741
