A heavy-duty 8′ rotary cutter designed for mowing thick grass, weeds, and brush up to 3″ in diameter. Built with a smooth-top 10-gauge steel deck, reinforced ¼″ side skirts, and high-capacity gearboxes (120 HP rated), it’s ideal for tough pasture, roadside, and field maintenance.
Model: HD-96
Cut Width: 96″
Overall Width: 105″ (lift and pull)
HP Required (Min.): 45 HP (lift); 35 HP (pull)
Gearbox Rating – Power Divider: 120 HP; 100HP
Bladetip Speed – Center: 15,480 FPM (540 RFM)
Cutting Capacity (Max.): 3″
Driveline Size – Main: Cat 4
Cross Shaft: Rubber Disc
Tires: Groved Laminated
Cutting Height: 2-12″
Hitch: Cat 1 and 2. QH
Tongue Weight: 900 LBS
Total Weight: 2200 lbs (Lift), 2400 (pull)
SIDE Band: 1/4″
Blades: 1/2″ x 4″ updraft
Blade Holder: Round
Deck: 10 gauge
Blade Overlap: 4″
Stump Jumper Size: 7 gauge
Leveling Rods: 2 on pull type
Overall Length: 91″ (Lift)
Driveline Protection: Slip Clutch
Chains: Single Chains
Transport Width: 105″
