Dimension:
- Operating Weight: 1,600 lbs
- Overall:
- Length: 122 in
- Width: 43 in
- Height: 86.5 in
- Track Size: 180*72*37 (Width*Pitch Length*Links)
Working Range:
- Max:
- Digging Depth: 71 in
- Digging Height: 118 in
- Dumping Height: 82.5
- Reach at Ground: 116.5
- Blade:
- Width: 35 in
- Height: 7.9 in
Engine:
- Brand: Rato
- Fuel:
- Type: Gas
- Capacity: 1.7 gal
- Consumption: 0.5-1.2 L/Hr
- Model: R420D
- Rated Power: 13.5 HP
- Displacement: 420 cc
- Hydraulic:
- Flow Rate: 21.6 L/min
- Pressure: 16 MPa
- Tank Capacity: 18L
