2024 LS MT232E-HT Tractor – Stock#0002861
618-658-1902
Advertised Price $28,508.50
Special Sale Price
Financing Options

The 2024 LS MT232E‑HT is a 31.7 hp entry-level compact tractor ideal for versatile small-farm and property maintenance tasks. Though the LS MT232E-HT Tractor is equipped with mechanical shuttle rather than hydrostatic drive, it’s comparable in specs to hydro versions in core lifting and hydraulic strength.

MakeLS Tractor
ModelMT232E-HT
Year2024
MilesNew

Key Features

  • Redesigned air conditioning and roof configuration, providing additional head space and increased forward visibility
  • Much improved seat comfortability
  • Factory A/C cab available in a 25HP tractor
  • New hood design (LS Family look), Grill open space plus 20%
  • LED head Lamp
  • 1 Inch large tire size and four different tire options
  • Larger lifting capacity, loader lifting capacity -> New MT226E (LL3301/2) 1,965 lbs. New MT2E & MT2(LL3303) 2,506 lbs.
  • Workability, 4-point mount structure as well -> digging depth of 97.2” and bucket digging force of 3,663 lbs.
  • TF-LCD instrument panel providing various information like, regen time, oil change interval, etc.
  • E/G RPM interlocking switch (STD). When working at low RPM, instantaneous RPM can be increased by simply manipulating the toggle switch to momentarily increase loader speed/lift (option).

Specifications

Engine

Type 3 Cylinder, Liquid-cooled, Diesel, NA, IDI
Model (Tier 4) YANMAR
Engine HP (Gross) 31.7
PTO HP 26.2
Rated Speed (RPM) 2,600
Displacement (cu. in) 100.2
Fuel Tank Capacity (gal) 10.6
Alternator (V-A) 12V – 55 Amps

Drive Train

Transmission Type HST
No. of Speed 3 Ranges
Brakes Wet, Multi-disc
Steering Hydrostatic Power Steering

PTO

Type Independent
Rear, rpm 540 (Standard)

Hydraulic System

Control System Position
Implement pump (gpm)  6.7
Steering pump (gpm) 5
Total flow (gpm) 11.7
Category, 3 pt hitch CAT I
Hitch Lift capacity, lbs (Hitch end) 1,808
Remote Valves Option

Dimension

Overall length (Frame to Link, in.) 125
Overall width with tires (in.) 66
Wheelbase (in.) 69
Height to top (in.) 95

Tire Size

Ag Front / Rear 7 – 14 / 11.2 – 24
IND Front / Rear 27X8.50-15 / 43X16.00-20
VT Front / Rear 27X8.50-15 / 43X16.00-20
Turf Front / Rear 25X8.50-14 / 41X14.00-20

Weight

Total weight without ballast (lbs.) 3,210
