NEW 2025 LS MT226E-HT-C Tractor – Stock#0003036
618-658-1902
Advertised Price $31,890.00
Financing Options

The 2025 LS MT226E-HT-C is a compact, high-performance tractor designed for a variety of agricultural, landscaping, and utility tasks. It features a 24.6-horsepower engine for reliable power and a 12×12 Synchro Shuttle transmission for smooth shifting. The tractor is equipped with a high-capacity loader, capable of lifting up to 1,965 lbs, and a three-point hitch with a lift capacity of 1,808 lbs. Its compact size and enhanced visibility make it ideal for maneuvering in tight spaces, while comfort features like a spacious cabin and air conditioning ensure ease of operation.

MakeLS Tractor
ModelMT226-HT-C
Year2025
MilesNew
Engine3 Cylinder, Liquid-cooled, Diesel, NA, IDI

Tab

Specifications

Specifications

Engine

Type 3 Cylinder, Liquid-cooled, Diesel, NA, IDI
Model (Tier 4) MHI
Engine HP (Gross) 24.6
PTO HP 19.2
Rated Speed (RPM) 2,500
Displacement (cu. in) 80.4
Fuel Tank Capacity (gal) 10.6
Alternator (V-A) 12V – 50 Amps

Drive Train

Transmission Type Synchro Shuttle
No. of Speed F12 X R12
Brakes Wet, Multi-disc
Steering Hydrostatic Power Steering

PTO

Type Independent
Rear, rpm 540 (Standard)

Hydraulic System

Control System Position
Implement pump (gpm) 7.9
Steering pump (gpm) 4.6
Total flow (gpm) 12.5
Category, 3 pt hitch CAT I
Hitch Lift capacity, lbs (Hitch end) 1,808
Remote Valves Option

Dimension

Overall length (Frame to Link, in.) 119
Overall width with tires (in.) 66
Wheelbase (in.) 66
Height to top (in.) 95

Tire Size

Ag Front / Rear 7 – 14 / 11.2 – 24
IND Front / Rear 27X8.50-15 / 43X16.00-20
VT Front / Rear 27X8.50-15 / 43X16.00-20
Turf Front / Rear 25X8.50-14 / 41X14.00-20

Weight

Total weight without ballast (lbs.) 2,985

Tab

Key Features

  • Redesigned air conditioning and roof configuration, providing additional head space and increased forward visibility
  • Much improved seat comfortability
  • Cruise control
  • Factory A/C cab available in a 25HP tractor
  • New hood design (LS Family look), Grill open space plus 20%
  • LED head Lamp
  • 1 Inch large tire size and four different tire options
  • Larger lifting capacity, loader lifting capacity -> New MT226E (LL3301/2) 1,965 lbs. New MT2E & MT2(LL3303) 2,506 lbs.
  • Workability, 4-point mount structure as well -> digging depth of 97.2” and bucket digging force of 3,663 lbs.
  • TF-LCD instrument panel providing various information like, regen time, oil change interval, etc.
  • E/G RPM interlocking switch (STD). When working at low RPM, instantaneous RPM can be increased by simply manipulating the toggle switch to momentarily increase loader speed/lift (option).

Options

LL3001, LL3002

  • Bucket (in.): 66
  • Maximum Lift height (in.): 94.3
  • Clearance with Attachment Dump (in.): 67
  • Reach at Maximum Height (in.): 14.4
  • Maximum Dump Angle (deg.): 48
  • Maximum Rollback Angle (deg.): 42.5
  • Digging Depth (in.): 4.8
  • Overall Height in Carry Position (in.): 51.2
  • Lift Capacity (Bucket Pivot Pin, MAX, Height) (lbs): 1,599
  • Lift Capacity (Pivot pin @ 1.5m) (lbs.): 1,965
  • Breakout Force(@ Pivot pin) (lbs.): 2,962
  • Approx. Weight (Loader w/o Bucket) (lbs.): 741
