Tomahawk 12′ Utility
Specifications
| GVWR | 7,000 -14,000 lbs |
| Weight | 1,600 – 2,300 lbs |
| Payload | 5,400 – 11,700 lbs |
| Lengths | 12 feet – 20 feet |
| Widths | 76″, 82″ |
| Frame | 2 x 3 x 1/4 Angle, 4″ Channel, 5″ Channel |
| Floor | No. 1 Grade 2″ Pressure Treated Pine with Slide In Decking |
Standard Features
| Axles | 3.5K, 6K, 7K |
| Tires | 205/75/15 8 ply , 225/75/15 10 ply, 235/80/16 10 ply |
| Coupler | 2″ Ram Bulldog , 2 5/16″ Ram Bulldog |
| Deck | 2 foot Dovetail or Flat |
| Tie Downs | State Pockets |
| Fenders | 72″ Diamond Double Broke |
| Ramps | 3ft gate, 4ft gate, 4ft ramps, 5ft ramps |
| Jack | 3K Top Wind Ram Jack, 8K 2-Stage Top Wind Ram Jack, 12.5K Spring Loaded HD Ram Jack |
| Tongue | Complete Wrap Tongue |
