Cutting Width: 60 inches
Cutting Height (1/2 inch increments): 1 to 6 inches
Tractor HP Range: 15 – 35 PTO
Type Hitch: Category I Size
Blades: 1/4 x 21/2 x 21 inches
Number of Blades: 3
Blade Tip Speed: 18,231 FPM
Blade Overlap: 11/2 inches
Blade Uplift: Parallel
Driveline Size: ASAE Category 3
Front Roller Size (optional): 3 x 5 inches
Discharge: Right Side
Deck Plate: 7 gauge
Tire Size (solid tire or pneumatic tire): 31/4 x 101/4 inches
Belt: “B” Size Kevlar
Gearbox: 45 HP
Tractor PTO Speed: 540 RPM
Belt Adjustment: Spring Loaded Idler
Approximate Weight: 560 lbs
