Tonutti Hay Rake is a high-quality, 10-wheel carted hay rake designed for efficient and gentle raking of forage crops. Its finger wheels, mounted on oscillating arms, follow ground contours to produce consistent and fluffy windrows suitable for baling. The rake features a single-acting hydraulic cylinder for convenient on-the-go adjustment from the tractor cab. Additional turnbuckles allow fine-tuning of the windrow width, enabling the formation of two windrows when needed. A shock-absorbing spring under each pivoting head ensures optimal ground pressure, even on uneven terrain. The wide cart and low center of gravity provide stability, making it suitable for use on inclines and hilly areas.
Tonutti Hay Rake Specifications
Wheels – 10
Wheel diameter – 55’’ (140 cm)
Tractor horsepower – 20 Hp (15 kW)
Hitch – Clevis
Maximum raking width – 22’ (660 cm)
Windrow width – 3’- 6’ (90 – 180 cm)
Weight – 1,174 lb. (534 kg)
Transport width – 10’4’’ (320 cm)
Appropriate working speed – 14 mph (22 kmh)
Minimum hydraulic requirements – 1,000 psi (68.95 bar)
Hitch jack – Standard
Tires – 185/65 – 14
